Soloscreen

​Known for it’s traditional design and balanced weave, Soloscreen is a an excellent fabric for solar control with versatile applications. Soloscreen is smooth to the touch and resistant to surface stains.

0.5% Privacy
Download 0.5% Line Card
1% Openness

SC SINGLE GLASS      SC INSULATING GLASS

1% Openness TS RS AS TV 1/8″ CL 1/4″ CL 1/4″ HA 1/2″ CL 1″ CL 1″ HA
White 20 70 10 17 0.31 0.32 0.31 0.29 0.30 0.24
White/Grey 10 52 38 6 0.42 0.41 0.36 0.40 0.38 0.29
White/Beige 14 60 26 9 0.37 0.37 0.34 0.35 0.35 0.27
Beige/Grey 10 41 49 6 0.50 0.48 0.39 0.47 0.44 0.32
Ash 5 32 63 3 0.55 0.53 0.42 0.52 0.49 0.35
Black/Pewter 2 15 83 2 0.66 0.62 0.47 0.62 0.57 0.39
Black 1 4 95 2 0.73 0.69 0.50 0.69 0.62 0.42

Black/Bronze

 2 8 90 2 0.71 0.67 0.49 0.67 0.60 0.41

TS = Solar Transmittance     AS = Solar Absorbance     CL = Clear Glass
HA = Heat Absorbing Glass     RS = Solar Reflectance     TV = Visual Transmittance

Download 1% Line Card
3% Openness

SC SINGLE GLASS      SC INSULATING GLASS

3% Openness TS RS AS TV 1/8″ CL 1/4″ CL 1/4″ HA 1/2″ CL 1″ CL 1″ HA
White 23 68 9 20 0.34 0.34 0.31 0.31 0.32 0.25
White/Grey 12 49 39 9 0.44 0.43 0.37 0.42 0.40 0.30
White/Beige 17 57 26 13 0.40 0.40 0.35 0.38 0.37 0.28
Beige/Grey 13 39 48 9 0.52 0.50 0.40 0.49 0.46 0.33
Ash 7 33 60 4 0.55 0.52 0.42 0.52 0.48 0.35
Black/Pewter 5 18 78 4 0.65 0.61 0.47 0.61 0.56 0.39
Black 3 4 93 5 0.73 0.69 0.51 0.69 0.63 0.43
Black/Bronze 5 9 86 7 0.70 0.67 0.49 0.67 0.63 0.43
Beige 14 54 32 7 0.41 0.41 0.36 0.39 0.38 0.29

TS = Solar Transmittance     AS = Solar Absorbance     CL = Clear Glass
HA = Heat Absorbing Glass     RS = Solar Reflectance     TV = Visual Transmittance

Download 3% Line Card
5% Openness

SC SINGLE GLASS      SC INSULATING GLASS

5% Openness TS RS AS TV 1/8″ CL 1/4″ CL 1/4″ HA 1/2″ CL 1″ CL 1″ HA
White 25 65 9 22 0.36 0.36 0.33 0.33 0.33 0.26
White/Grey 14 49 37 11 0.45 0.44 0.37 0.42 0.41 0.30
White/Beige 19 57 24 15 0.41 0.40 0.35 0.38 0.37 0.28
Beige/Grey 15 40 45 11 0.52 0.50 0.41 0.49 0.46 0.33
Ash 11 32 57 8 0.57 0.54 0.43 0.53 0.49 0.35
Black/Pewter 6 17 77 5 0.65 0.62 0.47 0.61 0.56 0.39
Black 5 4 91 8 0.74 0.70 0.51 0.70 0.63 0.43
Black/Bronze 7 8 85 10 0.71 0.68 0.50 0.68 0.61 0.43
Beige 15 53 31 9 0.41 0.41 0.36 0.39 0.38 0.29

TS = Solar Transmittance     AS = Solar Absorbance     CL = Clear Glass
HA = Heat Absorbing Glass     RS = Solar Reflectance     TV = Visual Transmittance

Download 5% Line Card

Specs:
Widths: 98″ and 118″
Roll Length: 32.8 Linear Yards
Fabric Weight: 0.5%: 14.16oz/yd  1%: 14.16oz/yd   3%: 12.98oz/yd   5%: 12.39oz/yd
Fabric Thickness: 0.5%: 0.026in    1%: 0.024in   3%: 0.024in   5%: 0.023in
UV Blockage: 0.5%: 99.5%  1%: 99%    3%: 97%    5%: 95%
Composition: 30% Polyester, 70% PVC

FIRE CLASSIFICATION: NFPA 701 TM#1 (small scale) TM#2 (large scale) NFPA 101 (class A rating) California U.S. Title 19 (small scale)
